| Encoder model: | EC08 series |
| name: |
EC08 Fexible Printed Circuit Encoder |
| Main specifications: |
Rated voltage: DC 5V |
| Features: |
Small size with large quantity (6PCS); FPC output. |
| Application areas: | Portable Rubik's Cube electronic toy products |
ONE、MECHANICAL CHARACTERISTIC
1. Rotational Torque: 5~40gf.cm
2. Total ratation angle: 360°
3. Number of detent: 0
TWO、ELECTRICAL CHARACTERISTIC
1. Resolution: 9 Pulses
2. Phase difference: ≥6ms
3. Rated voltage: DC 5V
4. Insulation Resistance: 50MΩ 1 Minute at DC 50V
5. Dielectric Voltage: 1 Minute at AC 50V
6. Chattering: ≤2ms
7. Bounce: ≤2ms
THREE、ENDURANCE CHARACTERISTIC
1. Rotational Life: 30,000 cycles Min
Note: In this catalog, if some parameters or drawings are different from the "Approvalsheet", it's subject to the "Approval sheet".
